7,500
25779
CAR CONNECTION INC.
1FDXE4FL0BDA30079
FORD ECONOLINE COMMERCIAL CUTAWAY 2011
7500.0000
General Information
No description available
- Standard Equipment
- Optional Equipment
- Additional Specifications
120 amp alternator
16" x 6" white painted steel wheels
4-wheel anti-lock brakes (ABS)
4.56 axle ratio
4600# capacity front coil springs
4600# capacity twin-I-beam front axle
5.4L EFI Triton V8 FFV engine *Gasoline only with 47A Ambulance Prep Pkg. FFV Capable with all other applications*
72 amp/hr (650 CCA) maintenance-free HD battery
9500# capacity full-floating rear axle
9500# capacity rear single-stage multi-leaf springs
Auxiliary fuel port
Black plastic step well pads
Black vinyl floor covering
Color-keyed cowl grab handles
Dash sound absorber
Driver & passenger black cowl trim panels
Dual color-keyed vinyl sunvisors
Dual note horn
Dual rear wheels
Front dome light
Front door courtesy light switches
Front stabilizer bars
Front vinyl-faced molded headliner
HD front/rear shocks
Interval windshield wipers
Key in ignition warning chime
Light & convenience group
LT225/75R16E all-season BSW tires
Medium flint-color door trim panels w/single stowage area
Medium flint-color seat belts w/height adjustable D-ring
Modified vehicle wiring kit & system
No spare tire & wheel
Painted black front bumper w/lower black plastic valence
Payload pkg -inc: 14050# GVWR
Pwr 4-wheel disc brakes
Pwr steering w/HD steering gear
Rear wheel drive
Rearview mirror delete
Sealed beam headlights
Slimline color-keyed engine cover console -inc: dual stowage bin, (3) cupholders
Solar tinted glass
Steel valve stems
Tilt steering wheel
5.4L EFI TRITON V8 FFV ENGINE
| Axle Capacity - Front | 4600 lbs |
|---|---|
| Axle Capacity - Rear | 9500 lbs |
| Axle Ratio (:1) - Rear | 4.56 |
| Axle Type - Front | Twin I-Beam |
| Axle Type - Rear | Full-Floating |
| Body Style | Cutaway DRW |
| Brake ABS System | 4-Wheel |
| Brake Type | Pwr |
| Cold Cranking Amps @ 0° F (Primary) | 650 |
| Disc - Front (Yes or ) | Yes |
| Disc - Rear (Yes or ) | Yes |
| Displacement | 5.4L/330 |
| Drivetrain | Rear Wheel Drive |
| Engine Order Code | 99L |
| Engine Type | Gas/Ethanol V8 |
| Fifth Gear Ratio (:1) | 0.71 |
| First Gear Ratio (:1) | 3.11 Range: 2.84 - 3.11 |
| Fourth Gear Ratio (:1) | 1.00 Range: 0.7 - 1 |
| Frame Type | Ladder |
| Frame Width, Rear | 42.0 in |
| Front Brake Rotor Diam x Thickness | 13.6 x 0.49 in |
| Front Head Room | 42.1 in |
| Front Hip Room | 65.5 in |
| Front Leg Room | 40.0 in |
| Front Shoulder Room | 68.1 in |
| Front Tire Capacity | 2680 lbs |
| Front Tire Order Code | T67 |
| Front Tire Size | LT225/75R16E |
| Front Wheel Material | Steel |
| Front Wheel Size | 16 x 6.0 in |
| Fuel System | SMFI |
| Fuel Tank Location | Aft Of Rear Axle |
| Gross Axle Wt Rating - Front | 5000 lbs |
| Gross Axle Wt Rating - Rear | 9500 lbs |
| Gross Combined Wt Rating | 20000 lbs |
| Ground Clearance, Front | - TBD - in |
|---|---|
| Ground Clearance, Rear | - TBD - in |
| Ground to Top of Frame | 20.6 in |
| Length, Overall w/o rear bumper | 261.1 in |
| Overhang, Front | 30.0 in |
| Rear Brake Rotor Diam x Thickness | 13.6 x 0.51 in |
| Rear Tire Capacity | 2680 lbs |
| Rear Tire Order Code | T67 |
| Rear Tire Size | LT225/75R16E |
| Rear Wheel Material | Steel |
| Rear Wheel Size | 16 x 6.0 in |
| Reverse Ratio (:1) | 2.88 Range: 2.32 - 2.88 |
| Revolutions/Mile @ 45 mph - Front | 709 Rev/Mile |
| Revolutions/Mile @ 45 mph - Rear | 709 Rev/Mile |
| SAE Net Horsepower @ RPM | 255 @ 4500 |
| SAE Net Torque @ RPM | 350 @ 2500 |
| Second Gear Ratio (:1) | 2.11 Range: 1.55 - 2.11 |
| Shock Absorber Diameter - Front | 35 mm |
| Shock Absorber Diameter - Rear | 35 mm |
| Spring Capacity - Front | 5000 lbs |
| Spring Capacity - Rear | 9500 lbs |
| Stabilizer Bar Diameter - Front | 0.91 in |
| Stabilizer Bar Diameter - Rear | 1.13 in |
| Steering Ratio (:1), At Lock | - TBD - |
| Steering Ratio (:1), On Center | 17.0 |
| Steering Type | Pwr |
| Suspension Type - Front | Coil |
| Suspension Type - Rear | 1-Stage Multi-Leaf |
| Third Gear Ratio (:1) | 1.55 Range: 1 - 1.55 |
| Total Cooling System Capacity | 28.3 qts Range: 28.3qts - 30.4qts |
| Trans Description Cont. | Automatic w/OD |
| Trans Order Code | 44T |
| Trans Type | 5 Range: 4 - 5 |
| Vehicle Name | Ford Econoline Commercial Cutaway |
